Wenglor B50 - Reference Image; Threshold Image

EN
142
Software Module
11.13.3.2. Reference Image
Objective
The taught in reference image is displayed after clicking the Reference Image.
Property
The following settings/results are displayed:
Image Type Display of the image type
X (px)
Coordinate of the sensor image coordinate system (see section 18.3)
Y (px)
Width (px) Image width
Height (px) Image height
The following settings/results are displayed under 8-bit:
Size Number of pixels in the image
Bits per Pixel Display of the number of bits required to transmit one
pixel
Channel Type The generic 8-bit channel type is displayed.
The following settings/results are displayed under Transformed Mask:
Size Number of pixels in the image
Bits per Pixel Display of the number of bits required to transmit one
pixel
Channel Type The mask channel type is displayed.
11.13.3.3. Threshold Image
Objective
The binary threshold image is displayed after clicking the Threshold Image.
Property
The following settings/results are displayed:
Image Type Display of the image type
X (px)
Coordinate of the sensor image coordinate system (see
section 18.3)
Y (px)
Width (px) Image width
Height (px) Image height
The following settings/results are displayed under 8-bit:
Size Number of pixels in the image
Bits per Pixel Display of the number of bits required to transmit one
pixel
Channel Type The generic 8-bit channel type is displayed.
