Software Module
11.24.3.1. RS-232
Objective
Transmit current results and data via the RS-232 port.
Property
The following settings/results appear.
Process Time [ms] Sensor processing time for the module
Module State Error codes to give support in error diagnosis (see section
18.5)
Preamble The characters specified here precede the output data.
Postamble The characters specified here follow the output data.
Delimiter The delimiter used to separate the individual data packets
from each other is specified here.
Output The preview of the output value is displayed, which consists of
preamble, delimiter and postamble.
String Count The number of desired values to be transmitted is defined.
String Count 1...8
The value can be entered statically or linked to a value. This
value is then transmitted via the interface.
