11.4.3. Configuration
The coordinate system module includes the following configuration options:
• Coordinate System
• Construction Method
11.4.3.1. Coordinate System
Objective
Details regarding the calculated output coordinate system can be displayed in the sub-
module. Input coordinate systems in the project tree can be linked against this output
coordinate system for tracking purpose.
Property
The following settings/results are displayed under origin:
Phi
(degrees)
Rotation of the coordinate system in degrees
X (px)
Coordinate of the sensor image coordinate system (see section 18.3)
Y (px)
11.4.3.2. Construction Method
Objective
Specify a point for setting up the X or Y-axis within the image. Various algorithms are
available.
Image Area
Depending on the construction method, either a fixed point or a search ray is displayed
in the image area. In the case of the search ray, the detected point appears purple.
