EN
82
Software Module
Property
The following settings/results appear – 1 to 3 points can appear depending on the
previously selected construction method.
Algorithm
Point 1
Selection for the construction method:
Fix A fixed point is specified as point 1.
Edge on Line An edge transition is looked for along a search
line. The detected point is specified as point 1.
Point (fixed or linked) A fixed point is specified as point 1. It’s also pos-
sible to use a result point from another module as
a coordinate point.
Edge on Line An edge transition is looked for along a search
line. The detected point is specified as point 1.
Edge on Arc An edge transition is looked for on an arc. The de-
tected point is specified as point 1.
Segment on Line Segments are looked for along a line. The center
of either the largest or the smallest segment can
be specified as point 1.
Segment on Arc Segments are looked for on an arc. The center of
either the largest or the smallest segment can be
specified as point 1.
Segment on Circle Segments are looked for on a circle.
The center of
either the largest or the smallest segment can be
specified as point 1.
Algorithm
Point 2
Selection for the construction method:
Fix A fixed point is specified as point 2.
Edge on Line An edge transition is looked for along a search
line. The detected point is specified as point 2.
Point (fixed or linked) A fixed point is specified as point 1. It’s also pos-
sible to use a result point from another module as
a coordinate point.
Edge on Line An edge transition is looked for along a search
line. The detected point is specified as point 1.
Edge on Arc An edge transition is looked for on an arc. The de-
tected point is specified as point 1.
Segment on Line Segments are looked for along a line. The center
of either the largest or the smallest segment can
be specified as point 1.
Segment on Arc Segments are looked for on an arc. The center of
either the largest or the smallest segment can be
specified as point 1.
Segment on Circle
Segments are looked for on a circle. The center of
either the largest or the smallest segment can be
specified as point 1.
