Software Module
Property
Module
Gap Min
Minimum gap in direction of the symbol rows and columns. Values: ’no’, ’small’,
’big’ Default: ’no’
Module
Gap Max
Maximum gap in direction of the symbol rows and columns. Values: ’no’, ’small’,
’big’ Default: ’small’ (Enhanced: ’big’)
Position
Pattern Min
Number of position detection patterns that have to be visible for generating a
new symbol candidate. Value range: [2, 3] Default: 3 (Enhanced: 2)
11.12.7. PDF417
Property
Symbol
Columns Min
Minimum number of data columns in the symbol in codewords, i.e., excluding
the codewords of the start/stop pattern and of the two row indicators. Value
range: [1 . . . 30] Default: 1
Symbol
Columns
Max
Maximum number of data columns in the symbol in codewords, i.e., excluding
the two codewords of the start/stop pattern and of the two indicators. Value
range: [1 . . . 30] Default: 20 (Enhanced: 30)
Symbol
Rows Min
Minimum number of module rows in the symbol.
Value range: [3 . . . 90] Default: 5 (Enhanced: 3)
Symbol
Rows Max
Maximum number of module rows in the symbol.
Value range: [3 . . . 90] Default: 45 (Enhanced: 90)
Module
Width Min
Minimum module width in the image in pixels.
Values: [1 . . . 100] Default: 3 (Enhanced: 2, Maximum: 1)
Module
Width Max
Maximum module width in the image in pixels.
Values: [2 . . . 100] Default: 15 (Enhanced: 100)
Module
Aspect
Min
Minimum module aspect ratio (module height to module width).
Values: [0.5 . . . 20.0] Default: 1.0
Module
Aspect
Max
Maximum module aspect ratio (module height to module width).
Values: [0.5 . . . 20.0] Default: 4.0 (Enhanced: 10.0)
