18.2. weQube status information
The following weQube status information may appear (see section “6.14. Status Information” on page 33).
Bit Section Signal Description
0 General Information Busy
1 Warning There is at least one bit set, level = Warning
2 Critical Error There is at least one bit set, level = Critical Error
3 Fatal Error There is at least one bit set, level = Fatal Error
4 reserved for future use, value=0
5 reserved for future use, value=0
6 Peripheral TCP/IP There is an error concerning the TCP/IP socket
7 UDP There is an error concerning the UDP socket
8 Industrial Ethernet There is an error concerning industrial ethernet
9 Camera There is an error concerning the built in image chip
10 Digital IO There is an error concerning the built in digital io stage or
the rotary decoder
11 Focus & Illumination There is an error concerning the built in
Focus&Illumination controller
12 UART There is an error concerning the UART device
13 reserved for future use, value=0
14 Memory Flash There is an error concerning the flash access
15 RAM There is an error concerning the RAM access
16 SD-Card There is an error concerning the sd-card access, 1 if not
mounted
17 File access There is an error concerning a general file access
18
Compatibility There is an error concerning the version of the loaded
project
19 reserved for future use, value=0
20 Temperature Over temperature The inside temperature is higher than a predefined level
21 Under temperature The inside temperature is lower than a predefined level
22 reserved for future use, value=0
23 reserved for future use, value=0
24 Image Processing Sequencing There is an error concerning IData vision engine
25 Processing There is an error concerning a vision module
26 Trigger There is an error concerning HW trigger
27 reserved for future use, value=0
28 reserved reserved for future use, value=0
29 reserved for future use, value=0
30 reserved for future use, value=0
31 reserved for future use, value=0
