Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
6.6.3. Selecting the Start Project
Set start project
Selecting the start project
Project_1
Project_2
Project_3
 Back
 Run
You can select a project from the project list in the “Set start project” menu, which is
then selected automatically when the sensor is started.
6.7. Configuration
Configuration
Managing sensor settings
Load
Save
 Back
 Run
Load: Settings saved to the SD card are loaded to the sensor.
Save: Settings currently loaded to the sensor are saved to the SD card. In the
event that the sensor is replaced, configuration of the new sensor is sim-
plified by simply replacing the SD card.
Caution: The previously stored sensor configuration is overwritten during the
save operation.
6.8. Interface
In addition to its serial port, the sensor is also equipped with an Ethernet port
Interface
Interface selection
Serial
Ethernet
 Back
 Run
Serial: The baud rate can be selected for the serial port.
Ethernet: Settings for the Ethernet port can be configured.
6.8.1. Serial interface
Activate
Baud rate selection for the serial port
O 9,600
O 19,200
O 38,400
O 115,200
 Back
 Run
Communication via the serial port can take place at various transmission speeds.
Changes do not become effective until after the sensor has been restarted.
