178

Software Module

Property

Slot 3-6

Data type The following types of data are avail-

able for transmission to the controller:

• 16 Byte Input (4 DINT).

• 16 Byte Input (4 REAL).

• 1 Byte Input (8 BOOL).

• 128 Byte Input (2 CHAR[64]).

• 1024 Byte Input (1 CHAR[1024]).

• 16 Byte Output (4 DINT).

• 16 Byte Output (4 REAL).

• 1 Byte Output (8 BOOL).

• 128 Byte Output (2 CHAR[64]).

• 32 byte input (2 CHAR[16])

• 64 byte input (2 CHAR[32])

• 256 byte input (2 CHAR[128])

• 512 byte input (2 CHAR[256])

• 32 byte output (2 CHAR[16])

• 64 byte output (2 CHAR[32])

• 256 byte output (2 CHAR[128])

• 512 byte output (2 CHAR[256])

Note: The sensor settings must correspond exactly to the controller settings.

The GSDML ﬁle is available from the download area on our website at wenglor.com.

The GSDML ﬁle is also included on the product CD provided with the sensor.
