Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
Connector Cables
M12, 12-pin to open end
ZDCL001 (straight) 2 m
ZDCL002 (straight) 5 m
ZDCL003 (straight) 10 m
ZDCL004 (angled) 2 m
ZDCL005 (angled) 5 m
ZDCL006 (angled) 10 m
Connection Cable
M12, 8-pin to RJ45
ZC1V001 2 m
ZAV50R502 5 m
ZC1V002 10 m
Mounting System
ZMBID1202
ZMWZF0001
Legend
Required accessories
Optional accessories
Included in delivery *
Lens
LAC9-14-K01 9 mm
LAC25-14-K02 25 mm
LAC35-16-K02 35 mm
Alternative Micro SD Card
ZNNG013*
Protection Housing
ZSZ-02-01
ZSZ-03-01
Illuminations
more Informations
> here
Connection Cable
M12, 12-pin to M12, 12-pin
ZDCV001 2 m
ZDCV002 5 m
ZDCV003 10 m
M12, 4-pin to M12, 4-pin
BW2SG2V1-2M 2 m
BG2SG2V1-2M 2 m
BG2SG2V3-2M 2 m
Connecting Module
M12, 12-pin to trigger / illumination
ZDCG001
Interface Cable
M12, 12-pin to RS-232
ZDCG002
Connection Cable
Connector Cables
Mounting System
Licenses:
ZNN1003 PC license, offline operation, 1D/2D code module
DNNL002 License, 1D/2D code module
DNNL001 License, vision module
DNNL003 License, OCR-Modul
Operating instructions:
ZNNG033 Operating instructions on CD
