7-2
IM DLM4038-02EN
7.1 Displaying FFT Waveforms
Setting the Vertical and Horizontal Scale Values (Display Setup)
Press the Display Setup soft key to display the following menu.
Turn the VT waveform display
on or off.
Manually set the vertical scale
values (using the jog shuttle).
Set the vertical scale values
(Auto, Manual).
Manually set
the center
point and span.
• Center point
• Span
• Center of the vertical axis
• Value per div
• Left side
• Right side
Manually set
the left and
right sides of
the axis.
Set the horizontal scale values
(Auto, Center/Span, Left/Right).
When Horiz. Scale Is Set
to Center/Span
When Horiz. Scale Is Set
to Left/Right
To Next Page
