18-8
IM DLM4038-02EN
18.6 Connecting to a Network Drive
This section explains the following settings (which are used when accessing a network drive through
an Ethernet connection to load or save various DLM4000 data).
• FTP server (file server)
• User name
• Password
• FTP passive mode
• Timeout
• Connecting to and disconnecting from network drives
► “Network Drive (Net Drive)” in the Features Guide
UTILITY Network Menu
Press UTILITY and then press the Network soft key to display the following menu.
Configure the network drive settings.
Configuring a Network Drive and Connecting to It (Net Drive)
Press the Net Drive soft key to display the following screen.
Disconnects from the network drive
Connects to the network drive
• Set the timeout value (0 to 60 s).
• Turns FTP passive mode on and off
• Enter the password using up to 14 characters.
• Set the user name.
• Set the FTP server’s host name.
Settings used to connect to a network drive
To Next Page
