6-5
IM DLM4038-02EN
6.4 Performing Integration
This section explains the following settings (which are used when performing integration).
• Operators
• Computation source waveforms
• Initial point
► “Operators (Operation)” in the Features Guide
MATH/REF Menu
Press MATH/REF to display the following menu.
Set the computation source waveform.
► section 6.2
Set the operator to Integ(S1).
Set Mode to Math.
Set the initial point.
Specify the computed waveform
from among Math1 to Math4 that
you want to configure.
Setting the Initial Point (Initial Point)
Press the Initial Point soft key to display the following menu.
Set the initial point to the specified value.
Set the initial point.
To Next Page
