4.3 Using the Snapshot and Clear Trace Features
► “Snapshot (SNAP SHOT)” and
“Clear Trace (CLEAR TRACE)”
in the Features Guide
Snapshot (SNAP SHOT)
1.
Press SNAP SHOT to retain the currently displayed waveform on the screen as a snapshot
displayed in white. Snapshot waveforms remain on the screen until you execute a clear trace
operation.
Note
When the color data setting is ON(Rev.) on the PRINT File menu, if you print the snapshot waveforms or
save them to a file, the waveforms may not be discernible.
Clear Trace (CLEAR TRACE)
2.
Press CLEAR TRACE to clear all the waveforms that are displayed on the screen.
