10-3

IM DLM4038-02EN

10.2 Zooming in on or out from Waveforms in the

Vertical Direction

This section explains the following settings (which are used when zooming in on or out from waveforms

in the vertical direction).

► “Vertical Zoom (Vertical Zoom)” in the Features Guide

ZOOM Vertical Zoom Menu

Press ZOOM1 or ZOOM2 and then the Vertical Zoom soft key to display the following menu.

• Zoom position

Set the vertical zoom.

• Zoom factor

Select the waveform that

you want to zoom in on.

Note

You can reset the zoom position and factor by pressing RESET.
