1.6 Configuring the Horizontal Axis (Time axis)

Set the time per grid (1 div) displayed on the screen.

Turn the TIME/DIV knob to set the value.

If you change the TIME/DIV setting while waveform acquisition is stopped, the waveform is displayed

expanded or reduced along the time axis.

► “Horizontal Axis (Time Axis)” in the Features Guide

TIME/DIV knob

See section 2.2.
