P1086708-001 ZXP Series 9 Card Printer Service Manual 3
Introduction
Printer and Laminator Components
Power Switch
Power Connector
DB9 Connection
USB Connection Ethernet Connection
Wi-Fi Antenna (optional)
Power Switch
Power Connection
DB9 Connection (optional)
USB Connection
Ethernet Connection
Wi-Fi Antenna (optional)
Icons
Throughout this manual, different icons highlight important information, as follows:
Indicates information that emphasizes or supplements important points of the main
text.
Advises you of information that is essential to complete a task, or points out the
importance of speciîšżc information in the text.
Warns you of the potential for electrostatic discharge.
Warns you of a potential electric shock situation.
Warns you of a situation where excessive heat could cause a burn.
Advises you that failure to take or avoid a speciîšżc action could result in physical
harm to you, or could result in physical damage to the hardware.
