Zebra ZXP 9 Series User Manual

170 ZXP Series 9 Card Printer Service Manual P1086708-001
Network Operations
Printer Pooling
Printer Pooling
Setting Up Printer Pooling (Windows 7)
Printer pooling is a standard feature of Windows, which lets you spread your printed output across a
pool of several printers.
Step 1. Before proceeding to pool any number of printers, test them individually to be sure
they are congured similarly. Specically, check the following:
y Ribbon panel conguration (ribbon type, and what prints on which side of the
card).
y Mag encoding conguration.
y Black extraction conguration (if applicable).
Step 2. From the Start menu select Devices and Printers. Right click on the Zebra ZXP
Series 8 Card Printer and select Properties, then select the Ports tab.
Step 3. Select the desired printers by clicking on the associated checkbox.
Step 4. Select the Enable printer pooling checkbox.
For setup on other operating systems, please refer to your system help content.

Zebra ZXP 9 Series Specifications

General

Resolution	300 dpi
Card Capacity Output	100 cards
Memory	64 MB
Interface	USB, Ethernet
Operating Humidity	20% to 80% non-condensing
Print Technology	Dye Sublimation
Print Speed YMCK	Up to 190 cards/hour
Card Capacity Input	100 cards
Card Sizes	CR-80 ISO 7810
Connectivity	USB, Ethernet
Operating System	Windows, Linux
Options	Magnetic stripe encoding
Power Requirements	100-240V AC, 50/60Hz
Operating Temperature	15°C to 35°C
Card Thickness	10-40 mil
