Zebra ZXP 9 Series User Manual

P1086708-001 ZXP Series 9 Card Printer Service Manual 229
Replacement Procedures for the Printer
Removal Sequence (continued)
Removal Sequence (continued)
Front Bezel
(Page 234)
Ribbon Take-
up Assembly
(Page 300)
Ribbon
Payout
Sensor
(Page 299)
EMI Line Filter
(Page 294)
Card
Transport
Assembly
(Page 339)
Card Infeed
Sensor
(Page 243)
Ribbon Take-
up Sensor
(Page 305)
Right Side
Cover
(Page 236)
Card Feeder
Assembly
(Page 240)
Printer Lock
(Page 341)
Tricolor
Sensor
(Page 290)
Operator
Control Panel
(OCP)
(Page 238)

Zebra ZXP 9 Series Specifications

General

Resolution	300 dpi
Card Capacity Output	100 cards
Memory	64 MB
Interface	USB, Ethernet
Operating Humidity	20% to 80% non-condensing
Print Technology	Dye Sublimation
Print Speed YMCK	Up to 190 cards/hour
Card Capacity Input	100 cards
Card Sizes	CR-80 ISO 7810
Connectivity	USB, Ethernet
Operating System	Windows, Linux
Options	Magnetic stripe encoding
Power Requirements	100-240V AC, 50/60Hz
Operating Temperature	15°C to 35°C
Card Thickness	10-40 mil
