16 ZXP Series 9 Card Printer Service Manual P1086708-001
Setup
Installing the Cleaning Roller
Installing the Cleaning Roller
The cleaning roller (Y-Cleaning Roller) cleans the cards entering the printer from either the input
hopper or the manual feed slot.
Step 4. Peel the protective wrapper from the cleaning roller.
Step 5. Install the cleaning cartridge into the area shown in the gure below by placing it into
the notches on the printer. Use the protective wrapper to push the cleaning roller into
place until it locks into position.
Note • To ensure print quality, the card cleaning cartridge requires periodic replacement.
New card cleaning rollers are included with each print ribbon or may be purchased
separately. Before replacing the card cleaning cartridge or its adhesive roller, clean
the printer (see “Cleaning the Printer” on page 60). To replace the Y-Roller, refer to
“Replacing the Cleaning Rollers” on page 62.

Zebra ZXP 9 Series Specifications

General

Resolution	300 dpi
Card Capacity Output	100 cards
Memory	64 MB
Interface	USB, Ethernet
Operating Humidity	20% to 80% non-condensing
Print Technology	Dye Sublimation
Print Speed YMCK	Up to 190 cards/hour
Card Capacity Input	100 cards
Card Sizes	CR-80 ISO 7810
Connectivity	USB, Ethernet
Operating System	Windows, Linux
Options	Magnetic stripe encoding
Power Requirements	100-240V AC, 50/60Hz
Operating Temperature	15°C to 35°C
Card Thickness	10-40 mil
