Zebra ZXP 9 Series

362 ZXP Series 9 Card Printer Service Manual P1086708-001
Replacement Procedures for the Laminator
Procedures: Back Cover
Back Cover
Step 1. With a TORX T10 driver, remove the three screws (circled below) holding the back
cover in place.
Step 2. Lift the back cover up and away from the laminator.
Step 3. Set the back cover aside.
