428 ZXP Series 9 Card Printer Service Manual P1086708-001
Smart Card Encoder
Media Loading Orientation
Media Loading Orientation
Contact Smart Cards
Place the cards in the input hopper with the gold-plated smart card contacts at the top surface of the
card and facing to the left (as shown).
Contactless Smart Cards
For contactless smart cards, orientation is not a consideration.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZXP 9 Series and is the answer not in the manual?

Zebra ZXP 9 Series Specifications

General IconGeneral
Resolution300 dpi
Card Capacity Output100 cards
Memory64 MB
InterfaceUSB, Ethernet
Operating Humidity20% to 80% non-condensing
Print TechnologyDye Sublimation
Print Speed YMCKUp to 190 cards/hour
Card Capacity Input100 cards
Card SizesCR-80 ISO 7810
ConnectivityUSB, Ethernet
Operating SystemWindows, Linux
OptionsMagnetic stripe encoding
Power Requirements100-240V AC, 50/60Hz
Operating Temperature15°C to 35°C
Card Thickness10-40 mil
