Zebra ZXP 9 Series

238 ZXP Series 9 Card Printer Service Manual P1086708-001
Replacement Procedures for the Printer
Procedures: Operator Control Panel (OCP)
Operator Control Panel (OCP)
For replacement, use Kit Operator Control Panel 105936G-012. Contact Zebra Customer Service
at +01 877-275-9327 for ordering information.
The operator control panel is mounted on the right side cover.
Step 1. With a TORX T10 driver, remove the four screws (circled below) holding the operator
control panel in place.
Step 2. Set the operator control panel aside.
