114 ZXP Series 9 Card Printer Service Manual P1086708-001
Theory of Operation
Main PCBA (CPU) Connections
Connector PCBA ID Functional Description
J1 EP-DEBUG Debug/Development ONLY
J2 IP-DEBUG Debug/Development ONLY
J3 RTU Ribbon Take-up Motor
J4 -
(P4A) Transfer Roller Motor, (P4B) Transfer Fan,
(P4C) Head Lift Motor, (P4D) Head Lift Sensor
J5 PH TU ENC Printhead Take Up Encoder Sensor
J6 DOOR Cover Switch
J7 PRNTHD PWR Printhead Power
J8 -
Smart Card Option (J2 on Smart Card) RF
Enable
J9 RFID 2 Future Use
J10 US ATH User Authentication
J11 UHF UHF Module Communication
J12 OCP Operator Control Panel
J13 -
(P13A) Ribbon P.O. Sensor, (P13B) Card Feeder
Sensor, (P13C) Ribbon P.O. Motor, (P13D) Card
X Motor, (P13E) Card Infeed Motor
J14 PS FAN Rear Exhaust Fan
J15 SPARE Future Use
J16 DUAL HOST 2 Port 2.0 USB Hub
J17 RF CONTACTLESS
Smart Card Option (J1 on Smart Card) USB
Communication to contactless encoder
J18 JTAG Debug/Development ONLY
J19 USB USB 2.0 Connector
J20 SPARE HOST Spare USB
J21 - Ethernet Daughter Card Contact
J22 - Debug/Development ONLY
J23 HAL LAMP CTRL Halogen Lamp Board Communication
J24 INTM
(P24A) INTM Lower Sensor, (P24B) INTM Bezel
Sensor, (P24C) INTM T.U. Sensor, (P24D) INTM
P.O. Motor, (P24E) INTM T.U. Motor, (P24F)
INTM T.U. Clutch
J25 SMT CARD Smart Card Motor
J26 MEDIA AUTH Media Authentication
J27 PHD DATA Printhead Data
J28 -
(P28A) Card Edge Detector, (P28B) Card Edge
Emitter, (P28C) Tri-Color, (P28D) Card Elevator
Motor, (P28E) Card Y Motor
J29 LAM Laminator Communication
J30 MAG HD Magnetic Read/Write Head (ISO or JIS II)
J31 INPUT PWR Input Power (24V)
J32 PHF Printhead Fan
J33 BL FAN Flash Blower Fan
To Next Page
