Zebra ZXP 9 Series

P1086708-001 ZXP Series 9 Card Printer Service Manual 281
Replacement Procedures for the Printer
Procedures: Printhead Lift Motor
Step 4. With a TORX T10 driver, remove the four screws (circled below) holding the motor in
place.
Step 5. Remove the printhead lift motor.
