P1086708-001 ZXP Series 9 Card Printer Service Manual 385
Replacement Procedures for the Laminator
Procedures: Cassette Latch Assembly (Top & Bottom)
Step 9. With a TORX T10 driver, re-install the two screws holding the latch plate in place.
Step 10. Release the top and bottom cassette torsion springs.
