Name Type Description
HMICTR7 INTEGER Bitmask output 7 to local remote LHMI input
HMICTR8 INTEGER Bitmask output 8 to local remote LHMI input
HMICTR9 INTEGER Bitmask output 9 to local remote LHMI input
HMICTR10 INTEGER Bitmask output 10 to local remote LHMI input
HMICTR11 INTEGER Bitmask output 11 to local remote LHMI input
HMICTR12 INTEGER Bitmask output 12 to local remote LHMI input
14.3.5.3 Settings
Table 407: LOCREM Non group settings (basic)
Name Values (Range) Unit Step Default Description
ControlMode Internal LR-switch
External LR-switch
- - Internal LR-switch Control mode for internal/external LR-
switch
14.3.5.4 Operation principle
The function block Local remote (LOCREM) handles the signals coming from the
local/remote switch. The connections are seen in Figure 333, where the inputs on
function block LOCREM are connected to binary inputs if an external switch is used.
When the local HMI is used, the inputs are not used. The switching between external
and local HMI source is done through the parameter ControlMode. The outputs from
the LOCREM function block control the output PSTO (Permitted Source To Operate)
on Bay control (QCBAY).
