ABB REG670 - Function Block

15.6.5.1 Function block
IEC04000405_2_en.vsd
OR
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
OUT
NOUT
IEC04000405 V2 EN
Figure 380: OR function block
15.6.5.2 Signals
Table 521: OR Input signals
Name Type Default Description
INPUT1 BOOLEAN 0 Input 1 to OR gate
INPUT2 BOOLEAN 0 Input 2 to OR gate
INPUT3 BOOLEAN 0 Input 3 to OR gate
INPUT4 BOOLEAN 0 Input 4 to OR gate
INPUT5 BOOLEAN 0 Input 5 to OR gate
INPUT6 BOOLEAN 0 Input 6 to OR gate
Table 522: OR Output signals
Name
Type Description
OUT BOOLEAN Output from OR gate
NOUT BOOLEAN Inverted output from OR gate
15.6.5.3 Technical data
Table 523: Number of OR instances
Logic block
Quantity with cycle time
3 ms 8 ms 100 ms
OR 60 60 160
15.6.6 Pulse timer function block PULSETIMER
The pulse (PULSETIMER) function can be used, for example, for pulse extensions or
limiting the operation time of outputs. The PULSETIMER has a settable length. When
the input is 1, the output will be 1 for the time set by the time delay parameter t. Then
it returns to 0.
Section 15 1MRK502052-UEN B
Logic
814
Technical manual
