Dst MACDst MAC - Type in the destination MAC address to be used with all PTP
unicast frames.
Touch the ARPARP button to solve any MAC setup in connection with IPv4.
Touch the NDP (NS/NA)NDP (NS/NA) button to solve any MAC setup in connection with
IPv6.
Src MACSrc MAC - Type in the source MAC address to be used with all PTP frames.
Select DefaultDefault to use the default MAC that comes with the Ethernet port.
EthertypeEthertype - Ethernet type is user-selectable only in case of VLAN use.
Select Multicast MAC addressSelect Multicast MAC address - The Multicast MAC address to be used in PTP
frames.
Automatic selectAutomatic select: - Multicast MAC address will be set depending on the
message.
01-80-C2-00-00-0E01-80-C2-00-00-0E: - Multicast MAC address used for non-peer-delay
measurement mechanism messages.
01-1B-19-00-00-0001-1B-19-00-00-00: - Multicast MAC address used for peer-delay
measurement mechanism messages.
VLAN layerVLAN layer
Select the number of levels using Level countLevel count drop down menu.
For each level select IDID, DEIDEI, PriorityPriority, and EthertypeEthertype.
MPLS layerMPLS layer
Select the number of levels using Level countLevel count drop down menu.
For each level select LabelLabel, EXPEXP, and TTLTTL. StackStack displays the stack bit.
IPv4 layerIPv4 layer
Src IPSrc IP - Type in the IPv4 source address.
Dst IPDst IP - In unicast mode type in the IPv4 destination address.
DSCP(PTP events message)DSCP(PTP events message) and DSCP(PTP other message)DSCP(PTP other message) - Set the DSCP
value to be used for transmitted PTP event frames and a value for all other
PTP frames. Acceptable values are between 0x00 and 0x3F.
IPv6 layerIPv6 layer
Src IPSrc IP - Select setting mode using drop-down menu.
ManualManual: touch the field to enter 32 Hex values.
StatelessStateless: configures the address automatically. The lamp lit in green if
the automatic configuration has succeeded.
Touching the SetupSetup button next to the virtual Lamp in the Src IPSrc IP
line will open the Stateless IPv6 SetupStateless IPv6 Setup dialog box.
Selecting the Use src MACUse src MAC check box configures the interface ID
from the MAC address.
When the check box is clear, touch the field to set the interface
ID.
Touching Renew nowRenew now starts the source IP address configuration.
Dst IPDst IP - In unicast mode type in the IPv6 destination address.
Multicast scopeMulticast scope - Select one of the predefined IPv6 multicast scope values or
choose User definedUser defined to manually enter a value. Acceptable values are
between 0x0 and 0xF.
Enable extension headerEnable extension header -Appends the IPv6 extension header. Touching
Extension headerExtension header opens the Extension Header dialog box.
