Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, fields for
specifying the ID will appear.
LengthLength
Only available if a Data or Test TLV type has been selected. Allows you to
specify the length of the TLV.
ValueValue
Only available if a Data or Test TLV type has been selected. Allows you to
specify the value of the TLV. Note that for the Data TLV type, this field is an
entry field where you open an editor and type the value; for the Test TLV type,
it is a drop-down menu.
LTM tab pageLTM tab page
The LTMLTM tab page contains the following parameters:
TTLTTL
Allows you to specify a TTL value. Used to indicate whether or not an LTM
should be terminated by the receiver.
Trans IDTrans ID
Allows you to specify the transaction number for the LTM.
TST tab pageTST tab page
The TSTTST tab page contains the following parameters:
Frames to sendFrames to send
Allows you to specify the number of frames to be transmitted.
RateRate
Use the drop-down menu to select the rate at which frames are transmitted.
Optional TLVOptional TLV
Use the drop-down menu to select the Test TLVTest TLV type, if relevant. Fields for
specifying the length and value will then appear.
LengthLength
Only available if the Test TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
Only available if the Test TLV type has been selected. Use the drop-down menu
to select the value of the TLV.
MCC tab pageMCC tab page
The MCCMCC tab page contains the following parameters:
OUIOUI
Allows you to specify the Organizationally Unique Identifier for the
organization defining a specific format and meaning of ETH-MCC.
