DataData
Allows you to specify any required additional information. The type of
information depends on the specific application of ETH-MCC.
LCK tab pageLCK tab page
The LCKLCK tab page contains the following parameters:
Client MEG levelClient MEG level
Allows you to specify the MEG level of the client MEG.
LCK rateLCK rate
Use the drop-down list to select the rate of the LCK frames being transmitted.
AIS tab pageAIS tab page
The AISAIS tab page contains the following parameters:
Client MEG levelClient MEG level
Allows you to specify the MEG level of the client MEG.
AIS rateAIS rate
Use the drop-down menu to select the rate of the AIS frames being transmitted.
1DM tab page1DM tab page
The 1DM1DM tab page contains the following parameters:
TypeType
Use the drop-down menu to select the relevant operation type (On-demandOn-demand
operationoperation or Proactive operationProactive operation). The same 1DM frame format can be used for
both.
RateRate
Use the drop-down menu to select the rate at which 1DM frames are
transmitted.
Frames to sendFrames to send
Allows you to specify the number of frames to transmit.
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, fields for
specifying the ID will appear.
LengthLength
Only available if a Data TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
Only available if a Data TLV type has been selected. Allows you to specify the
value of the TLV. Note that for the Data TLV type, this field is an entry field
where you open an editor and type the value.
