IDID
Only available if a Test TLV type has been selected. Allows you to specify the
value of the ID.
DMM tab pageDMM tab page
The DMMDMM tab page contains the following parameters:
TypeType
Use the drop-down menu to select the relevant operation type (On-demandOn-demand
operationoperation or Proactive operationProactive operation).
RateRate
Use the drop-down menu to select the rate at which DMM frames are
transmitted.
Frames to sendFrames to send
Allows you to specify the number of frames to transmit.
Delay thresholdDelay threshold
Allows you to specify a delay threshold that is used when a DMM test is active.
If the delay meets or exceeds that threshold, the user is alerted.
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, fields for
specifying the ID will appear.
LengthLength
Only available if a Data TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
Only available if a Data TLV type has been selected. Allows you to specify the
value of the TLV. Note that for the Data TLV type, this field is an entry field
where you open an editor and type the value.
IDID
Only available if a Test TLV type has been selected. Allows you to specify the
value of the ID.
LMM tab pageLMM tab page
The LMMLMM tab page contains the following parameters:
RateRate
Use the drop-down menu to select the rate at which LMM frames are
transmitted.
Frames to sendFrames to send
Allows you to specify the number of frames to transmit.
Loss thresholdLoss threshold
