TimingTiming
LinkLink
Link partner abilitiesLink partner abilities
Bit rateBit rate
The currently received bit rate is shown in bits per second (bps).
Bit rate differenceBit rate difference
The current difference between the received signal and the reference source
signal is shown in both parts per million (ppm) and bits per second (bps).
Accumulated Accumulated differencedifference
The accumulated difference between the received signal and the reference
source signal is shown. The information is presented as number of bits of
difference detected over the accumulation period.
This is important information for identifying small frequency differences, which may not
be visible by showing the current bit rate difference.
The accumulated difference information is accumulated continuously. The
accumulation is reset when measurement is started or restarted.
LOSLOS
Indicates whether LOS (Loss of Signal) of the transceiver is occurred or not.
LinkLink
Indicates whether Ethernet link is established or not.
Auto negotiation completeAuto negotiation complete
Indicates whether Auto negotiation is completed or not.
SpeedSpeed
10 Mbps, 100 Mbps, 1 Gbps or 10 Gbps is shown.
DuplexDuplex
FDX: Full Duplex, HDX: Half Duplex.
MDI/MDIXMDI/MDIX
MDI: Medium Dependent Interface, MDIX: Medium Dependent Interface
Crossover
Local clockLocal clock
Master or Slave is shown.
When
Electrical
interface type is selected, the Link partner abilities is shown.
Pause capablePause capable
Indicates in green when the device is capable of flow control using Pause
request.
Asym. pause requestAsym. pause request
Indicates in green when the device is capable of asymmetric flow control using
Pause request.
Remote faultRemote fault
Indicates in green when the device is sending the remote fault signal.
Speed/DuplexSpeed/Duplex
