Foreign MastersForeign Masters
802.3ah status802.3ah status
Shows the time source. The hexadecimal value of the time source in the PTP
packet data is displayed right-hand.
UTC offsetUTC offset
Shows the UTC offset provided by Announce Message from the Groundmaster
clock.
Provides a list of detected foreign masters. The identity of the current master is
shown in the field, the other masters are listed in a drop-down menu.
Port numberPort number
Shows the port number of the currently selected foreign master.
Announce countAnnounce count
Shows the number of Announce Messages received from the currently selected
foreign master.
66..11..33..77 OAMOAM
Touching the OAMOAM button in the status area of the Ports SetupPorts Setup screen displays
the status shown below.
This screen presents information about the status of the OAM functions. The
information is split up on a number of tab pages. Note that the layout of the
dialog depends on the currently selected OAM protocol.
