Y.1731 statusY.1731 status
informationinformation
LTMLTM: Enumerate and identify all hops between two end points.
Fault buttonFault button
The fault messages are sent when the button is active.
CCMCCM: Continuity Check Messages.
Devices tab pageDevices tab page
Shows the current status of the devices.
The outer circle of the colored Lamp in the Status column represents the CCM
status (green means that CCMs are received from that RMP, red means no
CCMs are received). The inner circle indicates whether the RDI bit in the CCM
frame is set (red) or not set (green).
Decode tab pageDecode tab page
Shows extra information about LTM frames.
Message buttonsMessage buttons
Allows you to send messages either to a remote MEP ID or to a unicast MAC
Address.
U-LBMU-LBM: Data-path integrity to/from the far-end to/from one address (unicast).
M-LBMM-LBM: Data-path integrity to/from the far-end to/from multiple addresses
(multicast).
LTMLTM: Enumerate and identify all hops between two end points.
MCCMCC: Maintenance communication channel message.
EXMEXM: Experimental message and response.
VSMVSM: Vendor-specific message and response.
TSTTST: Test message used for Bit Error Rate measurement and /or throughput
measurement.
LMMLMM: Determine packet loss.
SLMSLM: Determine frame loss.
DM1DM1: One-way delay measurements.
DMMDMM: Propagation delay between two end points.
