Application SelectorApplication Selector
Battery status
Refer to "Battery Status Information".
Link status of Ethernet service interface
WLAN (when the option is installed.)
Bluetooth (when the option is installed.)
VNC (Virtual Network Computing)
Controlled by the remote command
Connection status of GPS receiver
External PC status
Speaker On/Off status
44..11..33..11 Starting the ApplicationStarting the Application
The Application SelectorApplication Selector screen is the main entry point after startup of the
Network Master. From here you can choose which application/test to run:
either one of the standard applications or a previously saved pre-configured
application.
ApplicationsApplications
The icon you need may not be displayed because icons on screen are limited to four.
You may need to scroll the row of applications to display the relevant icon.
Touching + OTN+ OTN adds OTN layer for SDH/SONET Ethernet or Fibre Channel
applications.
Aside from the application buttons, the application selector screen also
contains a tab for showing/hiding the Instrument toolbar and a navigation tab
to the Result File Browser screen.
FavoritesFavorites
