Section 4 Basic Operation
4-36
4.8.2 Activating a tag
A tag can be activated by the following operation
(1) Move the cursor onto the parameter belonged to the tag.
(2) Move the cursor within the tag display area.
(3) Execute the tag selection menu in the function menu.
(1) Move the cursor onto a parameter belonged to the tag
In the common screen or setting window, tag can be activated by moving the cursor
onto a parameter belonged to the tag.
Example:
To activate Phone-1 tag on the System Configuration screen.
[Procedure]
1. Open Configuration screen.
2. Turn the encoder to move the cursor onto the GPIB Address-1. As GPIB Ad-
dress-1 is a parameter that belongs to Phone-1 tag, the Phone-1 tag becomes ac-
tive.
(2) Move the cursor within the tag display area
In the measurement result display window, the tag can be activated by moving the
cursor (line cursor) within the tag display area. The tag display area includes the
area between a tag and the next tag.
Example:
Activate the Occupied Bandwidth tag on the Fundamental Measurement
screen/measurement result window of W-CDMA measurement software.
[Procedure]
1. Open Fundamental Measurement screen.
2. Press
Focus
to activate the measurement result window by pressing.
3. Turn the encoder to move the cursor within the display area of the Occupied
Bandwidth tag.
