4.3 Operating a Screen
4-9
4.3 Operating a Screen
Screen indicates current operation status. Executable functions, display contents
and settable parameters vary depending on the screen. To execute a desired func-
tion, select a screen that allows to execute the function.
4.3.1 Screen type
The screens vary depending on the measurement software. They are classified into
the following two types according to their characteristics:
(1) Measurement screen (RF-1 Screen)
A screen to execute a measurement. The types and functions of the measure-
ment screens vary depending on measurement software products.
(2) Common Screen
The common screens provide the functions common for all measurement soft-
ware. Common screen includes the following screens. Measurement cannot
be executed when a common screen is selected.
• System Configuration screen (Setting systems/interface)
• System Information screen (Indicating system information)
• Parameter Save screen (Saving parameters)
• Parameter Recall screen (Reading parameters)
4.3.2 Selecting a screen
The screen is selected in the following three ways:
(1) Press
Screen
to open the screen selection list and select any screen
(2) Execute the screen selection function of the user menu
(3) Execute the screen selection function of the function menu
