Section 4 Basic Operation
4-6
4.1.4 User menu area
User menu area displays seven user menus. User menu is a list for executable
functions displayed on each screen or window. Press
U1
to
U7
user function
keys to execute a user menu.
4.1.5 Window area
Window area displays parameters and measurement results indicating MT8820A set-
tings and measurement conditions. Format and content of a window area differs
depending on the screen or window. For some screens, two windows are displayed
in upper and lower areas.
4.1.6 Entry area
Entry area is displayed when Pressing
Channel
or
Input Freq.
to enter
parameter for channel or input frequency or when specifying the parameter file num-
ber. It displays a numeric value being entered or error messages.
4.1.7 Function menu area
The function menu area displays seven function menus. The function menu is a list
for executable functions displayed on each screen or window. Press
F1
to
F7
user keys to execute a function.
4.1.8 Transmission-power monitor-value area
Transmission-power monitor-value area displays the measured monitor value of
transmission power for an active phone. The most accurate measurement result for
transmission power is displayed in the window area.
The transmission-power monitor value is displayed on the measurement screen only
and will be updated in a given time regardless of the start of measurement by
Single
, etc. Time for updating differs according to the measurement software.
This will not be displayed on the common screen.
