Anritsu MT8820A - Displaying the Date;Time or a Character String

6.1 Setting Systems and Interfaces
6-9
6.1.4 Displaying the date/time or a character string
The Title displayed in the upper left of the screen can be selected from among the
date/time, any character string, and display off. The date/time cannot be displayed
together with a character string.
Displaying the date and time
[Procedure]
1. Press
Config
to open the Configuration menu.
2. Press
F1
: System Config. to open the System Configuration screen.
3. Turn the encoder to move the cursor onto “Display Title”.
4. Press the encoder to open the popup window.
5. Turn the encoder to move the cursor onto “Time/Date”.
6. Press the encoder to display date and time.
Example of programming by remote control
TTL DATE
Displaying any character string
[Procedure]
1. Press
Config
to open the Configuration menu.
2. Press
F1
: System Config. to open the System Configuration screen.
3. Turn the encoder to move the cursor onto “Display Title”.
4. Press the encoder to open the popup window.
5. Turn the encoder to move the cursor onto “User Define”.
6. Press the encoder to display the character string.
Example of programming by remote control
TTL USER
Setting title display to Off
[Procedure]
1. Press
Config
to open the Configuration menu.
2. Press
F1
: System Config. to open the System Configuration screen.
3. Turn the encoder to move the cursor onto “Display Title”.
4. Press the encoder to open the popup window.
5. Turn the encoder to move the cursor onto “Off”.
6. Press the encoder to set the title display off.
Example of programming by remote control
TTL OFF
