4.4 Operating a Window
4-15
4.4.3 Activating a window
Press
Focus
to activate the window to be operated. Each time
Focus
is
pressed, active window changes in sequence. Press
Focus
until the desired
window becomes active.
4.4.4 Changing the window size
To display more parameters and items in a window, enlarge the window size. The
window size can only be changed in the vertical direction on the screen.
To change the window size, select “Window Size” from the function menu. Win-
dow size can be specified from Full Window, 70%, 50% or 30%, setting window area
vertical width as Full Window.
If two windows are displayed and when changing one window size, another window
size changes. For example, if lower active window is specified to display in 70%,
upper non-active window is displayed in 30%.
When setting the window size to 100%, all the opened window sizes are set to 100%
and an active window is displayed on the window. By pressing
Focus
, another
opened window is activated and displayed in the size of 100%.
Example:
To set the window size to 50%:
[Procedure]
1. Press
Next
to change the page of the function menu and display
Window Size
menu.
2. Press
F1
: Window Size to display Window Size of the function menu.
3. Press
F3
: 50% to change the proportion of the window
