Section 5 Using Common Functions
5-10
5.5 Hard Copy
Hard copy is a function to save an image displayed on LCD of MT8820A in the file.
This function is useful for recording the measurement result or waveform or pasting
on a report.
5.5.1 Media and format of the saving destination
A hard copy is saved in a memory card with a bitmap format file (extension: .bmp).
The file name is made of two parts: WCACP and a three-digit sequential number plus
“.bmp”. The smallest unused number from WCACP000.bmp. to WCAP999.bmp is
used. If there are already 1000 files from WCACP000.bmp. to WCAP999 in the save
destination folder, saving cannot be performed.
Note:
The file format for a memory card is MS-DOS.
5.5.2 Taking a hard copy
[Procedure]
1. Press
Copy
.
2. Copy completes when a message “Copy Complete” is displayed.
Note:
Never eject the memory card until a message “Copy Complete” is displayed.
