Section 6 Common Screen Functions
6-16
6.1.13 Setting 10Base-T default gateway
Set the Default Gateway that is used to connect to the external network using the
MT8820A data communication function. It’s default setting is 192.168.20.1.
Example:
To set default gateway to 192.168.0.1.
[Procedure]
1. Press
Config
to open the Configuration menu.
2. Press
F1
: System Config. to open the System Configuration screen.
3. Turn the encoder to move the cursor onto “Default Gateway” in “10Base-T 1.”
4. Press the encoder to open the popup window.
5. Press the numeric keypad to enter 192. Entering a 3-digit number moves the
cursor to the next entry box.
6. Press the numeric keypad to enter 168.
7. Press the numeric keypad to enter 0.
8. Move the cursor to the next entry box by pressing
>
.
9. Press the numeric keypad to enter 1.
10. Press
Set
to determine the value.
Example of programming by remote control
PSETDEFGTWY 192,168,0,1
