6.1 Setting Systems and Interfaces
6-15
The IP address for MT8820A can be set in “IP Address” within “10Base T-1” on the
System Configuration screen.
The subnet mask for MT8820A can be set in “Subnet Mask” within “10Base T-1” on
the System Configuration screen.
The default setting for the IP address is 192.168.20.2 and subnet mask is
255.255.255.0.
The IP address for the phone connected to Main 1 input/output connector can be set
on the measurement screen. For further details, refer to the manuals for measure-
ment software and options.
Note:
Before carrying out data communication with the MT8820A, be sure to con-
firm that the IP address, subnet mask and default gateway are all set correctly.
Example:
To set the IP address to 192.168.0.5 and subnet mask to 255.255.255.0.
[Procedure]
1. Press
Config
to open the Configuration menu.
2. Press
F1
: System Config. to open the System Configuration screen.
3. Turn the encoder to move the cursor onto “IP Address” in “10Base-T 1.”
4. Press the encoder to open the popup window.
5. Press the numeric keypad to enter 192. Entering a 3-digit number moves the
cursor to the next entry box.
6. Press the numeric keypad to enter 168.
7. Press the numeric keypad to enter 0.
8. Move the cursor to next entry box by pressing
>
.
9. Press the numeric keypad to enter 5.
10. Press
Set
to determine the value.
11. In the same manner, set subnet mask by moving cursor onto “Subnet Mask.”
Example of programming by remote control
PSETIPADDR 192,168,0,5
PSETSNM 255,255,255,0
