Anritsu MT8820A - Starting a Measurement in the Synchronous Single Mode; Stopping a Measurement

5.3 Starting a Measurement
5-7
5.3.4 Starting a measurement in the Synchronous single mode
[Procedure]
Transmits SWP command on the measurement screen.
Example of programming by remote control
SWP
5.3.5 Stopping a measurement
To stop a measurement under execution, press
Stop
on the front panel.
Under remote control, measurement start commands SNGLS, S2 (single) or CONT,
S1 (continuous mode) are used. If SWP or TS command is used, MEASSTOP is
not processed until the measurement ends.
To check if the measurement is being performed, view the measurement indicator er-
ror status area. Refer to “4.1.3 Measurement-indicator/error-status area”.
[Procedure]
Press
Stop
during the measurement.
Example of programming by remote control
SNGLS /*Starts a measurement in the single mode*/
MEASSTOP /*Stops a measurement*/
