8-6 Section 8 Remote Control Commands
8.1.5 Screen selection commands
The commands for selecting common function screens of Parameter Save screen, Parameter Recall screen etc. are listed in the
table below.
Table 8-1-5-1 Screen selection commands
Function Command Query Response Remarks
Parameter Save SCRSEL PRMSAVE PRMSAVE
Parameter Recall SCRSEL PRMRCL PRMRCL
System Configuration SCRSEL SYSCFG SYSCFG
Select Screen
System Information SCRSEL SYSINFO
SCRSEL?
SYSINFO
8.1.6 Measurement commands
The commands for starting and stopping measurement are listed in the table below. Measurement cannot be started from
common function screens.
Table 8-1-6-1 Measurement commands
Function Command Query Response Remarks
SNGLS ----- -----
Single
S2 ----- -----
SWP ----- -----
Single (Sync)
TS ----- -----
CONTS ----- -----
Continuous
S1 ----- -----
Current Status ----- SWP? status status = 0 Done or
1 Measuring
Stop Measure MEASSTOP ----- -----
