Anritsu MT8820A - Installation

2.2 Installation
2-19
2.2.2 Installation
Install MT8820A horizontally in a stable place at a low-drift temperature between 0
and 50°C. Keep the rear and sides of MT8820A at least 10 cm apart from obstacles
such as walls and peripherals in order to provide space around the exhaust holes.
Keep at lease 10 cm
apart
Keep at lease
10 cm apart
Keep at lease
10 cm apart
Fig. 2-2-2-1 Installation place
Anrits u
MT8820A
Fig. 2-2-2-2 Installation direction
