Section 7 Remote Control Using PC
7-24
Table 7-6-6-2 Description of each bit of END event status register
When using CDMA2000 measurement software
Bit Description
7 Not used
6 Not used
5 Not used
4 Not used
3 Indicates that transmission measurements on the Fundamental
Measurement screen have been completed, except for Access Prove
Power.
2
Indicates that reception measurement on the Fundamental Measurement
screen has been completed.
1 Indicates that the measurement for Access Prove Power on the
Fundamental Measurement screen has been completed.
0 Indicates that measurements for all selected items have been completed.
Table 7-6-6-3 Description of each bit of END event status register
When using PDC measurement software
Bit Description
7 Not used
6 Not used
5 Not used
4 Not used
3 Indicates that transmission measurements on the Fundamental
Measurement screen have been completed.
2 Indicates that reception measurement on the Fundamental Measurement
screen has been completed.
1
Indicates that the measurement for Access Prove Power on the
Fundamental Measurement screen has been completed.
0 Measurement/Sweep Completed
Occurs when measurement or sweep has been completed.
 Query
Read using the ESR2? query. When readout is successful, the contents of the
register are cleared.
Example:
Query ESR2?
Response 1
(1 = 2
0
bit0: Measurement/sweep is completed)
 Clear
The following methods are available to clear the END status register.
• Read the status using the ESR2? command
• Send the *CLS command
• Turn the power On.
