Section 1 Product Overview
1-8.
Table 1-4-2 Specifications (Signal generator)
Item Specification
RF signal generator Frequency
• Frequency range: 30 to 2700 MHz (settable range: 0.4 to 2700 MHz)
• Setting resolution: 1 Hz
• By the accuracy of Standard Signal Generator
Output level
• Level range: −140 to −10 dBm (Main 1), −130 to 0 dBm (AUX1)
• Resolution: 0.1 dB
• Level accuracy:
Main 1: ±1.0 dB (−120 to −10 dBm, after calibration)
AUX 1: ±1.0 dB (−110 to 0 dBm, after calibration)
Signal purity
• Non-harmonic spurious: −50 dBc (at offset frequency of 100 kHz or more,
except for [up frequency − down frequency +
4.1825 GHz])
−40 dBc (in ≥2.1 GHz, spurious at [4.8 GHz −
down frequency GHz])
• Harmonics: ≤ −25dBc
Un-interruptable level variable
• Variable range: 0 to −30 dB
• Set resolution: 1 dB
Other Display
• Color TFT LCD, Size: 8.4", Number of dots: 640 × 480 dots
External control
• GPIB: Controlled by an external controller, assuming the MT8820A as a
device (except some functions such as power switch etc.). No controller
function
• Interface function: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Power 100 to 120 Vac/200 to 240 Vac (−15%/+15%, maximum: 250 V)
47.5 to 63 Hz, ≤ 300 VA (Option 01 installed)
Dimensions, Mass 426 mm (W), 221.5mm (H), 498mm (D) (except protrusions), ≤ 23 kg
Operating temperature
and humidity range
0 to 50°C, ≤ 95% (no condensation)
Storage temperature and
humidity
−20 to +60°C, ≤ 85% (no condensation)
EMC EN61326: 1997/A1:1998 (class A)
In conformance with EN61000-3-2 1995/A2:1998, class A)
In conformance with EN61326:1997/A1:1998 (Attached document A)
Security In conformance with EN61010-1:1993/A2:1995 (installation category II,
pollution level II)
