9.1 Performance Test
9-19
VSWR value for AUX auxiliary output connector
Connector VSWR measurement value Specified max. value Measurement inaccuracy
AUX 1 1.3 0.02
Output frequency of RF signal generator
Setting Result
30 MHz  OK  NG
100 MHz  OK  NG
300 MHz  OK  NG
600 MHz  OK  NG
1000 MHz  OK  NG
1500 MHz  OK  NG
2000 MHz  OK  NG
2500 MHz  OK  NG
2700 MHz  OK  NG
Optional setting value MHz  OK  NG
Optional setting value MHz
 OK  NG
Optional setting value MHz
 OK  NG
Output level accuracy of RF signal generator (Main1)
Output level frequency characteristics
Setting
Frequency Output level
Result
Measurement
inaccuracy
30 MHz
1000 MHz
2000 MHz
2700 MHz
−10 dBm ±0.12 dB
