Section 2 Setup
2-16
14 15 16 17 18 19
20
Fig. 2-1-3-3 Rear panel (3)
14. 10Base-T-2 10Base-T port 2
Currently not available.
15. 10Base-T-1 10Base-T port 1
An interface for packet or communication test allocated to Phone 1.
16. 10/100Base-T 10/100Base- T port
Currently not available.
17. Serial Bus-2 Serial bus connector 2
Currently not available.
18. Serial Bus-1 Serial bus connector 1
An interface for packet or communication test allocated to Phone 1.
19. Grounding terminal
Connect a grounding lead here to ground MT8820A to the ground potential.
20. Power inlet Power cable inlet. Permissible power range is 100 to 120 Vac or
200 to 240 Vac (47.5 to 63 Hz). This power inlet supports both 100 and 200-
V system with no need to make particular setting change.
